SPECIFICATIONS

Cartridge Specifications

Cartridge Type - Moving Coil, Low Output

Output Level - 0.5 mV at 5 cm/s

Load Impedance - 400 to 500 Ohms recommended

Frequency Response - 20Hz to 50kHz

Channel Separation - Greater than 30dB at 1Khz

Compliance - 6 x 10-6 cm/dyne

Recommended Tracking Force - 2.4 g

Channel Difference - Less than 0.3dB at 1kHz

Total Mass - 11 g

Stylus - Elliptical Diamond

Cantilever Material - Aluminum

Tonearm Specifications

Bearing - Sapphire and Ceramic

Arm Tube - Dural-Aluminum

Counterweight - Eccentric

Adjustments - Vertical Tracking Angle, Antiskate, Azimuth

Turntable Specifications

Playback Speeds - 33-1/3, 45 and 78 rpm

Motor Type - DC Brushless

Speed Control - Electronic w/ braking feature

Platter - Silicon Acrylic

Platter Bearing - Magnetic Suspended Ceramic

Signal To Noise Ratio - 41dB - 44dB

Wow & Flutter - 0.10% - 0.15%

Connectivity

Stereo Outputs Unbalanced - 1

Control

Power Control Input - 1

Power Control Output - 1

Platter Light - Yes

Speed Control Fine Adjustment - Yes

General Specifications

Dust Cover Included - No

Weights & Dimensions

Dimensions (W x H x D) -

17-1/2" (44.45cm) x 8-13/16" (22.38cm) x 21" (53.34cm)

Note: Tone Arm Height will vary depending on the type of Cartridge installed.

Weight - 42 lbs (19 kg)

Shipping Weight 63 lbs (28.6 kg)
