Product Details
＋
- White powder-coated steel cabinet, high-quality matt white
- Advanced tubular motor for quiet, fast
- Endcap remote control receiver, ( sizes larger than 150" have external remote receiver )
- IR with extended IR probe and RF remote
- 12-volt trigger @
- Mounting brackets & fasteners & remote
- Aspect ratios available 1:1, 4:3, 16:9 and 16:10
- 12 MONTHS RTB WARRANTY
TECHNICAL SPECIFICATIONS
| Format | Diag. Size (inch) | Viewing area W x H (mm) | Case Length (mm) | Total Height (mm) | Black Drop (mm) | Packing Size (mm) LxWxH | Gross Weight (kg) |
| 1:1 | 96 | 2440 x 2440 | 2710 | 2670 | 60 | 2965 x 175 x 130 | 16 |
| 4:3 | 84 | 1710 x 1280 | 1980 | 1520 | 60 | 2215 x 175 x 130 | 10.5 |
| 100 | 2030 x 1520 | 2300 | 1760 | 60 | 2565 x 175 x 130 | 11.5 | |
| 120 | 2440 x 1830 | 2710 | 2070 | 60 | 2965 x 175 x 130 | 13 | |
| 150 | 3050 x 2285 | 3320 | 2585 | 100 | 3550 x 190 x 145 | 25 | |
| 173 | 3515 x 2636 | 3805 | 2936 | 100 | 4030 x 195 x 190 | 41 | |
|
16:9 | 92 | 2030 x 1140 | 2300 | 1760 | 450 | 2565 x 175 x 130 | 11 |
| 106 | 2345 x 1320 | 2610 | 1890 | 400 | 2880 x 175 x 130 | 12.5 | |
| 119 | 2635 x 1480 | 2895 | 1960 | 300 | 3160 x 175 x 130 | 14 | |
| 133 | 2950 x 1655 | 3220 | 2010 | 150 | 3450 x 190 x 145 | 23.5 | |
| 150 | 3320 x 1780 | 3590 | 2150 | 100 | 3830 x 190 x 145 | 26.5 | |
| 173 | 3830 x 2154 | 4120 | 2454 | 100 | 4340 x 195 x 190 | 44 | |
| 196 | 4339 x 2440 | 4629 | 2740 | 100 | 4850 x 195 x 190 | 50.5 | |
| 16:10 | 92 | 1980 x 1240 | 2300 | 1760 | 450 | 2565 x 175 x 130 | 11 |
| 106 | 2280 x 1425 | 2610 | 1890 | 400 | 2880 x 175 x 130 | 12.5 | |
| 119 | 2560 x 1600 | 2895 | 1960 | 300 | 3160 x 175 x 130 | 14 | |
| 133 | 2860 x 1790 | 3220 | 2010 | 150 | 3450 x 190 x 145 | 23.5 | |
| 150 | 3230 x 2020 | 3525 with internal remote | 2290 | 100 | 3450 x 185 x 135 | 29 |
| Format | Diag. Size (inch) | Viewing area W x H (mm) | Case Length (mm) | Total Height (mm) | Black Drop (mm) | Packing Size (mm) LxWxH | Gross Weight (kg) |
| 16:10 | 173 | 3726 x 2329 | 4016 | 2629 | 100 | 4310 x 195 x 190 | 44 |
| 196 | 4222 x 2638 | 4510 with internal remote | 3068 | 100 | 4532 x 195 x 190 | 50.5 |
