Drives even the most demanding speakers

A push-pull amplifier, delivering 80W/channel into 8 ohms and 160W/channel into 4 ohms, effortlessly accommodates a range of speaker types and impedances.

Seamlessly integrate high-resolution digital audio

Digital connections, including optical, coaxial, and USB-B, support up to 384kHz/32- bit. Ultra AL32 Processing waveform interpolation produces smooth, high-resolution sound.

Unlock your vinyl collections full potential

The PMA-3000NEs phono stage supports both MM and MC cartridges, for the most faithful sonic reproduction regardless of cartridge type.

Specifications

Performance

• Rated Output Power:
  • 80W 80W (8, 20 Hz 20 kHz, THD 0.07%)
  • 160W 160W (4, 1 kHz, THD 0.7%)
• Total Harmonic Distortion (THD):
  • 0.01% (Rated output: 3 dB, 8, 1 kHz)

Input Sensitivity & Impedance

• Phono Input:
  • MM: 2.5 mV / 47 k
  • MC: 200 V / 100
• CD/Line/Recorder: 135 mV / 19 k
• Power Amp Input (EXT. PRE): 0.9 V / 47 k

Signal-to-Noise Ratio (SNR)

• Phono MM: 89 dB
• Phono MC: 74 dB
• CD: 107 dB

Power Consumption

• Normal Operation: 400 W
• Standby:
  • 0.2 W (TV Autoplay Off)
  • 0.4 W (TV Autoplay On)

Audio Features

• Power Amplifier Circuit: New UHC-MOS Single Push Pull (7)
• Preamplifier Circuit: Variable Gain Preamplifier (OP AMP)
• Tone & Balance Control:
  • Bass: Yes
  • Treble: Yes
  • Mid: No
  • Balance: Yes
• Source Direct: Yes
• Analog Amp Mode: Yes (Button on front panel)

Digital Features

• DAC Circuit: ES9018K2M 4
• Digital Processing: Ultra AL32 Processing
• DAC Master Clock Design: Yes
• Asynchronous Mode (USB-B): Yes

General Details

• Dimensions (W H D):
  • 434 182 443 mm
• Net Weight: 24.6 kg
