Product Details
＋
Key Features
- White in-ceiling aluminium case
- High-quality tab-tensioned, fibreglass,
- Available in Matt White fabric & (Grey High Contrast fabric*)
- White aluminium weight bar to keep the fabric flat
- Advanced tubular motor for fast, quiet
- External remote control receiver, RF remote, 12v trigger,
- Mounting brackets & fasteners remote cradle
- Sizes are viewing sizes
- Aspect ratios available 16:9 and 16:10
*16:9 Only
Warranty
- 12 Month RTB Warranty
- Specifications and warranty subject to change without
Technical Specifications
|
Format | Diag. Size (inch) | Viewing area W x H (mm) | Case Length (mm) | Total Height (mm) | Black Drop (mm) | Packing Size (mm) LxWxH | Gross Weight (kg) | Screen Case with Installation Brackets | Ceiling Opening Length Needed | Distance between installation screws |
| 16:9 | 92 HD3-T-IC | 2030 x 1140 | 2500 | 1680 | 300 | 2730 x 220 x 250 | 34 | 2550 | 2580 | 2530 |
| 106 HD3-T-IC | 2345 x 1320 | 2815 | 1860 | 300 | 3045 x 220 x 250 | 38 | 2865 | 2895 | 2845 | |
| 119 HD3-T-IC | 2635 x 1480 | 3105 | 2020 | 300 | 3335 x 220 x 250 | 41 | 3155 | 3185 | 3135 | |
| 133 HD3-T-IC | 2950 x 1655 | 3420 | 2210 | 150 | 3650 x 220 x 250 | 45 | 3470 | 3500 | 3450 | |
| 16:10 | 92 HD3-T-IC | 1980 x 1240 | 2450 | 1780 | 300 | 2680 x 220 x 250 | 34 | 2500 | 2530 | 2480 |
| 106 HD3-T-IC | 2280 x 1425 | 2750 | 1990 | 300 | 2980 x 220 x 250 | 37 | 2800 | 2830 | 2780 | |
| 119 HD3-T-IC | 2560 x 1600 | 3030 | 2010 | 150 | 3260 x 220 x 250 | 41 | 3080 | 3110 | 3060 | |
| 133 HD3-T-IC | 2860 x 1790 | 3330 | 2130 | 100 | 3560 x 220 x 250 | 44 | 3380 | 3410 | 3360 | |
| 150 HD3-T-IC | 3230 x 2020 | 3700 with internal remote | 2360 | 100 | 3930 x 220 x 250 | 46 | 3750 | 3780 | 3730 |
Width between the installation screws: 180mm Ceiling Opening Width Needed: 160mm
