Featuring a fully discrete, two stage design for minimal interference, and unique Marantz HDAM technology for signal purity, MODEL 30 offers exceptional sound quality.
Key Features
A masterpiece of audio architecture
Tuned with passion - Hundreds of hours of thoughtful Sound Master tuning ensure the exquisite detail and musicality Marantz always delivers.
Designed to last - You see and feel it in the build quality and you hear it every time. No matter your musical passions, your music always sounds better with MODEL 30.
Fully discrete and accurate detailing - Marantz HDAM-SA3 technology is comprised of dozens of independent parts, each hand-selected for pure, detailed Marantz sound.
Extraordinary sensitivity - Designed to replicate the sensitivity and feel of a vintage analog amplifier even when simply adjusting the volume.
Exquisite sound tuning - MODEL 30 continues the renowned heritage of exquisite Marantz amplifiers. Tuned by the Marantz Sound Master who channeled his passion, experience, and extraordinary ear into the amplifier design.
The most musical, accurate, detailed sound - MODEL 30 is built on its own discrete circuit board, the Hyper-Dynamic Amplifier Module, or HDAM.
Marantz Musical Premium Phono EQ - Envisioned to deliver optimal sound quality by simplifying the signal path vital given the delicate nature of phono signals the Phono EQ stage in MODEL 30 can be used with both moving magnet and low-output moving coil cartridges, thanks to a built-in MC head amplifier.
MC / MM phono input impedance selector - In order to optimize sound performance when using a moving coil (MC) or magnetic moving (MM) cartridge, and to accommodate all configurations as much as possible, MODEL 30 is equipped with an input impedance selector.
Built for Generations - Like its counterpart, the SACD 30n Streaming CD Player, the MODEL 30 Integrated Amplifier is designed to the highest standards.
More Than 65 Years of Audiophile Heritage - Founded in 1953, Marantz has a long and rich history of designing audio components embraced by music lovers and critical listeners around the world.
SPECIFICATIONS
Features
| Aluminium extrusion heat sink | o (Separate) |
| Balance / Bass / Treble / Loudness | o / o / o / - |
| Channels | 2 |
| Current Feedback Topology | o |
| Customised Components | o |
| Digital in: USB-B / optical / coaxial / USB-A | - / - / - / - |
| HDAM version | SA3, SA2 |
| High Grade Audio Components | o |
| Phono EQ: Standard / Marantz Musical / Marantz Musical Premium | - / - / o |
| Power Transformer: Toroidal / El | SMPS |
| Symmetric PCB Layout | o |
General
| Auto power off | o |
| Carton Maximum Dimensions (W x D x H) in mm | 534 x 522 x 255 |
| Carton Weight (inc. product) in kg | 17.6 |
| Detachable Power Cable | o |
| Maximum Dimensions (W x D x H) in mm | 443 x 431 x 130 |
| Metal Front Panel | o |
| Power Consumption in W | 130 |
| Remote Control | RC002PMND |
| Standby Consumption in W | 0.2 |
| System Remote Function | o |
| Weight in kg | 14.8 |
Inputs/Outputs
| Audio Inputs | 6 |
| Audio Outputs | 1 |
| Balanced In / Out | - / - |
| D-Bus | o |
| Digital in: USB-B / optical / coaxial / USB-A | - / - / - / - |
| Floating Control Bus (3.5 mm mono jack x 2) | - |
| Gold Plated Cinch | o |
| HDMI: inputs / outputs | - |
| Headphone Gain Control (low / mid / high) | - |
| Headphone Out | o |
| Number of terminals | 2 |
| Phono Input: MM / MC | o / o |
| Power Amp Direct IN | o |
| Pre-out / Main-in | o / - |
| Speaker A / B | - |
| Speaker Terminals | Marantz SPKT-100 |
Others
| 5mm aluminium top plate | - |
| BI-AMP and Multichannel option | - |
| Double Layer Bottom Plate | o |
| Input buffer amp (all inputs / CD only) | - / - |
| Linear Drive Power Supply | o (pre-amplifier stage) |
| Liniear volume control | o |
| Low noise LCD display | - |
| Low Noise OELD display | o |
| Marantz Musical Digital Filtering | - |
| Power Amp direct | - |
| Shottky diodes | o |
| Source Direct | - |
| System block shielding: copper / metal / none | o / - / - |
Specifications
| Damping Factor | 500 |
| Frequency Response | 5 Hz - 50kHz |
| Input Sensitivity: Balanced High level | - |
| Input Sensitivity: High level | 220 mV / 13 kohm |
| Input Sensitivity: MC | 250 |
| Input Sensitivity: MM | 2.3 mV / 39 kohm |
| Input Sensitivity: Power Amp Direct IN | - |
| Power Output (8 / 4 Ohm RMS) | 100 W / 200 W |
| Signal to Noise Ratio: High level | 107 dB(2V input/Rated output) |
| Signal to Noise Ratio: MM / MC | 88 / 75 dB |
| Signal to Noise Ratio: Power Amp Direct IN | - |
| Total Harmonic Distortion | 0.005% |
