Product Details
＋
Specifications
Product:
- Commercial Model: 100U7K
- Factory Model: 100E80KAVS
- Factory: Qingdao
- Description: 254cm (100) Direct LED Television
Document:
- Specifications Form Version: HA230216
- Circulation: Restricted, internal use only
- Status: Confirmed
- Revision Number: 1
- Date: 2023/03/16
- Issued By: Al
Image Display:
- Panel Manufacturer: Hisense
- Panel Model: LCM, Open Cell: T850QVN03.7
- Active Display Area, Horizontal Dimension: 2203
- Active Display Area, Vertical Dimension: 1239
- Screen Size: 100"
- Display Technology: LCD/LED lit
- Backlight Source: Direct LED
- Resolution (Horiz x Vert): 3840X2160
- Color Depth: 8bit FRC
- Image Refresh Frequency: 144
- Smooth Motion Rate: 240
- 3D Image: -
- Typical Brightness of White: 500
- Native Contrast Ratio: 5000:1
- Viewing Angle (Horiz/Vert): 178/178
- Quantum Dot: Yes
- Wide Color Gamut: Yes
- KSF Phosphor: No
- UHD Premium: No
- Response Time: 6.5
Connectivity:
- RF-Radio Frequency Input: 1
- AV Input: 1
- AV Output: 0
- USB Interface Type 3.0 (Qty/List): 1/USB1
- USB Interface Type 2.0 (Qty/List): 1/USB2
- Optical Digital Audio Output (SPDIF): 1
- Earphone Jack: 1
- HDMI Ports:
- HDMI Inputs: 4
- HDMI Type 8K@60Hz: No
- HDMI Type 4K@60Hz with HDCP Version 2.2: Yes
- HDMI 2.1 Compliant Input: Yes/HDMI 3 & 4
- Enhanced Audio Return Channel (eARC): Yes/HDMI 3
- CEC-Consumer Electronics Control via HDMI: Yes
Smart TV:
- Ethernet Port (RJ45 Connector): 1
- Wi-Fi Protocols IEEE 802.11: a, b, g, n, ac
- Wi-Fi Bands: 2.4/5.0
- DLNA Compliance: Yes
- Bluetooth/BT Version: Yes/5.0
- Anyview (Screen Mirroring): Yes
- BVOD Services: Iview, SBS on Demand, 9Now
- Installed Applications: Netflix/Youtube/Prime Video
- Freeview Plus-HbbTV 2.0: Yes
- Web Browser: Odin
Digital TV Reception:
- Digital Broadcasting (DVB-T/DVB-T2): Yes/Yes
- Video Decoder (MPEG2/MPEG 4): Yes/Yes
- LCN-Logical Channel Number and DTV Service Name Support: Yes
- Teletext/Teletext Signal Interruption (TAB Compliant/16:9 TLTX): Yes/Yes/4:3
- Subtitles: Yes
- EPG-Electronic Programming Guide, 7 Days for All Services: Yes
- Audio Description (Vision Impairment Aid): Yes
- Parental Rating Lock: Yes
- Analog Tuner: Yes
Image Processing:
- Backlight Control: Yes
- Light Sensing: Yes
- Dynamic Backlight Control: Yes
- Frame Rate Control: No
- Variable Refresh Rate (VRR): Yes
- FreeSync: Yes
- Auto Low Latency Mode for VRR: Yes
- Local Dimming/Controllable Zones: Yes/1296
- Zoom Function Settings: Auto/16:9/4:3/21:9/Movie Zoom/Dot to Dot
HDR-High Dynamic Range:
- HDR for Luminance (DMP/Netflix/HDMI): Yes/Yes/Yes
- HDR System (HDR10/HDR10 /Dolby Vision): Yes/Yes/Yes
- HLG (Hybrid Log-Gamma) for HDR: Yes
- HEVC (H.265) Decoder: Yes
- Motion Enhancement and Compensation (MEMC): Yes
- Picture Mode: Standard, Cinema Day, Cinema Night, Dynamic, Sports
Sound:
- Audio Power Output Per Channel: 215W 20W 25W
- Number of Speakers (Tweeter/Midrange/Woofer): 2/2/1
- Automatic Volume Level (AVL): Yes
- Audio Equalizer: Yes
- Dolby Digital: Yes
- Audio Enhancement-Type: Dolby ATMOS
- Lip-sync Adjustment: Yes
- Sound Mode: Stand, Theatre, Music, Speech, Late Night, Sports
Features:
- On/Off Timer: Yes
- Power Off if No Signal: Yes
- Sleep Timer: Yes
- Program Lock: Yes
- OSD Transparency Control: Yes
- User Interface: VIDAA U7
- Software Version OSD Indication: Yes
- Legal Requirements: Disclaimer/Acceptance of Terms (Yes/Yes)
- Favorite Channels List: Yes
- Electronic Point of Sales (E-POS): Yes
- OTA-Over the Air Software Updates: Yes
- Voice Command: Yes
- Screen Mirroring: Anyview Cast
- Smartphone Remote Control Application: Vidaa App
- Replaceable Demo Video for Store Mode: Yes
- Remote Control via Serial Port: No
USB Media Player:
- Personal Video Recorder: Yes
- Time Shift: Yes
- DTV Recording (EPG Scheduling/Start from Standby): Yes/Yes
- DivX Decoder: No
- MPEG4 (H.264)/H.265 Decoder: Yes/Yes
- DMP-Digital Media Player Content (Music/Video/Photos/Text): Yes/Yes/Yes/No
- DMP Auto-play: No
- DMP for UHD Content via USB: Yes
- DMP File Allocation Table (FAT/FAT32/exFAT/NTFS): Yes/Yes/No/Yes
- PVR File Allocation Table (FAT/FAT32/exFAT/NTFS): Yes/Yes/No/Yes
Hotel Lock:
- Protected Hotel Lock Submenu (Password/Fixed Code): No/Yes
- Clone Function for Programs, Sound, and Image Settings: Yes
- Sub-menu Lock, Including Tuning Lock: Yes
- Keyboard Lock: Yes
- Maximum Volume Lock: Yes
- Power On Volume: Yes
- Power On, Apply Default Sound/Image Settings: No
- Power On Source Selection: Yes
- Power On RF Channel Selection: Yes
- Power On Mode (On/Standby/Last): Yes/Yes/Yes
- Inputs Access (Enable/Disable): Yes
Hardware:
- Processor/Cores: MT9618BAATAB
- Dual Tuner: No
- Color (Front Bezel, Rear, Stand): Tarnish/Black/Tarnish
- Speakers Mounted in Enclosure: Yes
- Mains Power Switch: No
- Swivel Base: No
- Compact Packaging: Yes
- Supply Range (Voltage/Frequency): AC100~240V,50Hz/60Hz
- Standby Consumption: < 0.5W
- Maximum Time Delay Power On to Sound an Image: 30
Installation:
- Stand Area (Width/Depth): 1682455
- Wall Mount Dimensions (Horiz x Vert): 600400
- Wall Mount, Screw Thread: M8/10
- VESA Compliance: Yes
- Detachable Power Cord: Yes
- Power Cord Length: 200
Accessories:
- Remote Controller (Technology/Part Number): IR/ERF2R36H
- Battery (Size/Quantity): AAA/2
- User Manual (Available Online)/Quick Setup Guide (Print): 1/1
- Warranty: In Separate Sheet
Dimensions:
- Dimensions with Stand (W x H x D): 22351318500
- Dimensions without Stand (W x H x D): 2235128690
- Carton Box Dimensions (W x H x D): 24022971514
- Net Weight (With Stand/Without Stand): 73.5 Kg/71.3 Kg
- Gross Weight: 100 Kg
- Container Load (20ft/40ft/40ft HC): 35 (40ft HC)
Licensing and Certification:
- EMC-Electromagnetic Compatibility: Yes
- CB-Electrical Safety: Yes
- HDMI: Yes (Hisense internal test)
- Dolby Digital: Yes
- MEPS-Test Report: Yes
- ROHS: No
- Electrical Safety Conformity for Australia: Yes
Documentation:
- CB Report and Certificate: Yes
- EMC Report and Certificate: Yes
- Power Cord, Plug, and Connector Australian Safety Approval: Yes
